ION
PIN
W225P2
Design: Dirk Winkel
Don’t let Ion’s delicate lines deceive you – behind its almost weightless appearance lie serious engineering and high-performance light. The clever friction joint allows for free 360° positioning with both accuracy and staying power, enabling smooth shifts between focused task lighting and more ambient use. The pin-mounted version allows for discreet desk integration, creating a minimal footprint and an even cleaner overall expression. Two 40 cm arm sections and a wide beam angle offer flexibility for a range of uses.
Art. No. 182B23009
For professional inquiries please contact us
here.Downloads
Technical specifications
Mounting Type
Table | Pin
Material
Lamp Body: Aluminium
IP Rating
IP20
Protection class
Class II
Colour Rendering Index
CRI 98
Light source
COB LED
Life time expectancy
L80 / 50000h
Stand. deviation of colour
3 SDCM (initial MacAdam)
Colour Temperature
3000 K
Luminous flux
526 lm
Voltage
100 - 240 V
Power
8.3 W
Light control
Integrated dimmer switch
Net Weight
0.3 kg
Replaceability Control Gear
Replaceable control gear by an end-user
Replaceability Light Source
Replaceable light source by a professional
Variants
Art. No. / EAN code
-
-
-
225P20530W
/
7330492017327
